High quality P10 320x160 outdoor LED module
Handles and cable holes
Waterproof rubber strip and eaves
High quality P10 320×160 outdoor LED module.
The brightness reaches 7500 cd / ㎡, the module size is 320x160mm, the refresh rate reaches 3840Hz, and three anti-paints are sprayed on the back, which can be used in combination with high-quality cabinets to achieve IP65 protection level.
Using MRV336 receiving card, this type of receiving card can not only use common sending equipment (such as sending card), but also use a computer to directly output signals through the network cable interface.
Single card supports 24 groups of RGB signal output. The maximum load is 256×226 pixels.
Use high-quality MEAN WELL NEL-400-5 power supply, automatically adapt to wide voltage.
Output: 5V 60A
4 high quality cooling fans installed in each cabinet
The handle allows the installer to better secure the cabinet. The handle is placed in a special groove and does not take up extra space.
The waterproof eaves and the high-quality waterproof sealing strip on the back of the cabinet ensure that users do not need to worry about the risk of water ingress during normal use.
