GOB LED Display Module

A GOB LED display module uses Glue on Board technology: a transparent protective resin covers the LED surface to help resist moisture, dust and accidental contact. EagerLED supplies GOB LED modules from Shenzhen, China, for LED video wall projects. Compare the 320x160mm, 250x250mm and other module series below, then request a specification matched to your screen.

  • Moisture Protection
  • Impact Resistance
  • Protected LED Surface
  • Clear Image Display
  • 2 YEARS WARRANTY

Inquiry Now

Moisture Protection for GOB LED Modules

The resin coating seals the LED face and helps protect exposed components from moisture. For outdoor projects, check the specified module and complete cabinet separately: surface protection alone does not make every GOB LED screen waterproof. Ask for the selected model’s IP rating, test conditions and installation requirements before ordering.

Impact Resistance During Handling and Installation

The protective layer helps shield small LED packages from accidental knocks during transport, installation and servicing. This can be useful for rental displays and screens within reach of people. GOB modules still need protective packaging, careful handling and a suitable cabinet; the coating does not make the panel unbreakable.

Dust Protection and Surface Care

The sealed face limits dust entry around the LEDs and provides a more continuous surface than exposed LED packages. Keep the display clean using the care method approved for its coating. Avoid abrasive tools and unapproved solvents, and retain access to the cabinet for routine inspection and maintenance.

Image Quality Beyond the Protective Coating

Transparent encapsulation allows light from the LEDs to pass through the protective layer. Final image quality also depends on pixel pitch, LED selection, brightness, calibration and driver settings. For meeting rooms, retail displays or camera-facing installations, compare sample images at the intended brightness and confirm the refresh rate for the selected module.

Flexible GOB LED Modules for Curved Screens

GOB protection can be applied to compatible soft LED modules as well as rigid boards. For curved displays, confirm the permitted bend radius, mounting method and coating compatibility before choosing a module. See our flexible LED display modules and specify whether your project is a fixed installation or a frequently assembled rental screen.

GOB LED Module Product Photos

GOB LED Display Aging Test

How to Choose a GOB LED Display Module

Start with the viewing distance, screen dimensions and installation environment. A smaller pixel pitch provides more pixels within the same screen area, but module size alone does not indicate image resolution. Use the specification tables below to compare the available models.

  • Pixel pitch and resolution: match the detail level to your content and nearest viewers.
  • Mechanical fit: verify module dimensions, mounting holes, cabinet layout and service access.
  • Electrical compatibility: confirm power requirements, connectors, scan mode, receiving card and configuration files.
  • Operating conditions: check brightness, refresh rate, ventilation and the protection rating required by the site.
  • Maintenance: plan compatible spare modules and confirm the repair process for the resin-coated face.

For replacement orders, send photos of the front and rear, the module label and existing control configuration. Matching dimensions and pixel pitch alone is not enough to guarantee compatibility.

GOB Module Supply from Shenzhen, China

EagerLED is based in Shenzhen and supplies LED display products for international projects. When requesting a quote for the United States, Malaysia, Mexico, the UAE, India or another destination, include the installation city, indoor or outdoor use, quantity and required delivery date. Confirm the applicable electrical requirements, compliance documents, shipping terms and spare-parts plan for your market with our team.

Browse our LED display module range if you are comparing other module types.

320x160mm Series GOB LED Screen Panel

250x250mm Series GOB LED Display Panel

Other Series GOB LED Screen Module

GOB LED Display Module FAQ

01. What is a GOB LED display module?

A GOB LED display module is an LED board with a transparent protective resin layer over its LED surface. GOB stands for Glue on Board. The coating helps protect the LEDs from dust, moisture and incidental contact while allowing the display to produce an image.

02. What is the difference between GOB, SMD and COB?

SMD describes packaged LEDs mounted on a circuit board. GOB adds a protective coating over the assembled LED surface, often on an SMD module. COB uses LED chips mounted directly on the substrate and encapsulated. Compare the actual pixel pitch, image quality, protection and repair method rather than choosing by the technology name alone. Read our COB vs GOB comparison for more detail.

03. Can GOB LED modules be used outdoors?

Only choose a model and cabinet specified for the outdoor conditions of your project. GOB surface protection does not replace weatherproof cabinets, sealed connectors, suitable brightness or thermal management. Request confirmation of the complete screen’s protection rating and operating limits.

04. Which module size and pixel pitch should I choose?

Compare the 320x160mm, 250x250mm and other series in the tables above. Choose pixel pitch for the viewing distance and required resolution, then check the cabinet layout and control system. Ask EagerLED to confirm the exact module specification before purchase.

05. What determines the GOB LED display module price?

Price depends on pixel pitch, module dimensions, LED and driver components, coating specification, quantity and required accessories. Send your screen size or module quantity, application and delivery destination for an itemized quote. Confirm whether the quotation includes control equipment, power supplies, spare modules and freight.

06. Can I replace a standard LED module with a GOB module?

A replacement must match the mechanical and electrical design of the existing screen, including pixel pitch, resolution, mounting, connectors, scan mode and controller configuration. The coating can also affect surface appearance. Confirm compatibility and color matching before mixing modules in one display.

07. Is GOB protection available for flexible rental screens?

It can be used on compatible flexible modules. For repeated event use, confirm the minimum bend radius, approved handling procedure and cabinet support. Describe how often the screen will be assembled and transported so the module and protection system can be assessed for that use.

08. What should international buyers include in an inquiry?

Provide the destination country and city, screen dimensions, viewing distance, indoor or outdoor environment, module quantity and project schedule. Request the model specification, applicable compliance documentation, warranty terms and shipping quotation. This helps align the proposed GOB LED screen with local installation requirements.
